PWAS Monitoring & Safety Solutions
Engineered for Precision. Built for Safety. Trusted by Fleets. Monitoring Solution
Innovation
AI-driven monitoring and proximity detection.
Reliability
IP67/IP68-rated ruggedized devices for extreme conditions.
Compliance
Aramco Approved with timestamped video and event logs for audit readiness .
Why Proximity Warning Alert System (PWAS)?
The Safety Gap You Can’t Ignore
Industrial and commercial fleets operate in dynamic environments where blind spots and reversing zones pose serious risks. Proximity Warning Alert System PWAS delivers a proactive safety net through AI-powered proximity alerts and HD video monitoring to prevent accidents and protect lives.
Industrial Hardware Durability : Tough Gear for Tough Jobs
Uninterrupted Data Protection
Uninterrupted Data Protection
- Expandable Storage – SD card capacity up to 256GB with loop recording.
- Built-in UPS (Uninterruptible Power Supply) – Keeps recording active during power failures.
- Tamper-Proof Security – TS file format preserves data integrity.
- Industrial Reliability – Consistent performance even in harsh and high-vibration environments.
Capture, Review & Improve
Capture, Review & Improve
- 1080P HD Recording – Crystal-clear footage with efficient H.264 compression.
- Forensic Integrity – Timestamp watermarking ensures legal-grade evidence.
- Flexible Playback – Online review and backup to external systems for incident investigations.
Driver-Centric Situational
Driver-Centric Situational Awareness
- 10.1-inch HD Control Screen – Clear visuals with intuitive system management.
- Multi-View Layouts – Up to 5 Picture-in-Picture (PIP) combinations for full coverage.
- Smart Overlays – Object identification markers and driver reminders.
- Customizable Reverse Delay – Adjustable (0–10 seconds) for safe and comfortable maneuvering.
Industrial Hardware Durability :
Tough Gear for Tough Jobs
AHD Cameras
Engineered for durability and clarity in demanding environments.
1:Resolution: 720P / 1080P (Analog High Definition)
2:IP68 rating: waterproof, dustproof, shockproof
3:Night vision with 18 infrared LEDs
4:Wide-angle field of view for blind spot coverage
5:Vibration-resistant casing suitable for mining and logistics
Sirens & LED Warning Lights
Ensures visibility and awareness in high-risk zones.
- IP67-certified hardware
- Operating temperature: -20°C to +70°C
- High-intensity LED lights for low-visibility operations
- Audio sirens with high-decibel output for noisy industrial environments
- Resistant to shocks and vibrations in construction or port operations
HD Mobile DVR (Digital Video Recorder)
Reliable evidence capture and secure fleet monitoring.
- Supports up to 6 camera channels (default 4 for blind spot coverage)
- 1080P recording across all channels
- Compression: H.264 for optimized file size
- Data security: TS format for video integrity
- Power backup: Built-in UPS ensures no data loss during outages
- Integration: Compatible with Eagle-IoT platforms for fleet-wide monitoring
Wearable Safety Tags
Personal protection for workers in proximity to vehicles.
- Lightweight, wireless design
- Operates in defined detection zones around heavy machinery
- Alerts vehicle operators when personnel enter danger zones
- Long battery life with low-power alerts
- Rugged casing for industrial use
Vehicle-Mounted Sensors
Smart detection for fleet operators.
- Detects pedestrians and vehicles in real time
- Works in tandem with cameras and driver display
- Configurable detection ranges
- Operates in extreme temperature and vibration conditions
- Waterproof and dustproof design
Tailored Detection for Every Vehicle Type
Who Needs PWAS?
Proximity Warning Alert System PWAS is designed for fleets that operate in people-heavy, equipment-dense environments.
Frequently Asked Questions (FAQ)
What type of cameras does PWAS support?
PWAS supports AHD (Analog High Definition) cameras with 720P/1080P resolution. Each camera is IP68-rated for waterproof and dustproof protection, with shock resistance and night vision powered by 18 infrared LEDs.
How many camera channels can the system support simultaneously?
The system supports up to 6 camera channels, with real-time multi-angle detection (rear, left, right). The default configuration includes 4 channels for full blind-spot coverage.
Can detection zones be customized per vehicle?
Yes, the system allows manual configuration of detection zones for each side of the vehicle. This ensures tailored BSD (Blind Spot Detection) coverage based on vehicle dimensions, operating environment, and fleet-specific needs.
What triggers the pedestrian/vehicle alert system?
The system’s AI algorithm constantly monitors each camera feed. When a pedestrian or vehicle is detected within the configured danger zone, it sends visual alerts to the display and audible alerts through the built-in speaker system. The reverse alarm is only activated when the reverse gear is engaged.
What display interface is used?
PWAS features a 10.1-inch high-resolution display with support for up to 5 dynamic Picture-in-Picture (PIP) layouts, providing real-time situational awareness. Optional overlays such as object ID markers and reminder boxes can be enabled.
Does the system support video recording and playback?
Yes, it supports Full HD 1920x1080P video recording using H.264 compression. Playback can be accessed locally or remotely with optional timestamp watermarking for evidential integrity.
What storage options are available?
PWAS supports SD cards up to 256GB and features automatic loop recording. It also includes a built-in UPS (Uninterruptible Power Supply) to ensure recording continuity during power interruptions.
Can the system be integrated with external monitoring or fleet platforms?
Yes, Eagle-IoT PWAS is designed to export video and alert data via USB or remote connection, allowing integration with Eagle-IoT fleet management platforms or incident review systems.
Are reverse guidelines and delays configurable?
Absolutely. The system includes customizable reversing guidelines and an adjustable delay trigger (0–10 seconds), allowing time buffer customization for enhanced driver comfort and safety.
What operating conditions can the hardware withstand?
All core hardware is rated for –20°C to +70°C operating temperatures. Sirens and warning lights are IP67-rated, ensuring reliable performance in dusty, wet, and extreme temperature environments.
How does PWAS reduce false alarms?
PWAS uses AI-powered algorithms and customizable blind spot zones to filter out irrelevant objects. This ensures only real risks trigger alerts, improving driver confidence.
PWAS Monitoring – Industrial Strength Safety for Fleets That Cannot Compromise.
Make your fleet smarter, safer, and legally protected—without adding more manual workload.
